Justfill Pdf Forms

by mrmaciej1

318 downloads

Not rated

GitHub Website

About

Fill any PDF form with AI agents — ML field detection on scans, visual review loop, reusable templates, and native AcroForm fill via justfill.app.

Details

Author: mrmaciej1
Downloads: 318
Categories: Productivity, Other, File Management, Automation, AI

- Opens PDFs (including scanned images) and detects form fields
- Three resolution modes: saved template (deterministic), AcroForm (native), ML detection
- Confidence scores (0–1) for each ML-detected field, with raw score preserved
- Preview renders with color-coded field boxes and filled values before committing
- Field editing (add, update, remove) with batch operations and bulk pruning
- Saves reviewed layouts as templates for deterministic future fills

Setting up with Highlight

This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:

Download and install Highlight from highlightai.com/download
Navigate to the plugins tab and select "Add Custom Plugin"
Configure the plugin with the settings below

Plugin Name Justfill Pdf Forms

Command (node, npx, python, etc.)

Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
Enable "Start Automatically" if you want the plugin to start when Highlight launches

Setting up with Cursor

Open Cursor's settings
Navigate to the MCP section
Click "Add new Global MCP server"
Copy and paste the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

Setting up with Claude Desktop

Open Claude Desktop's settings
Go to the Integrations tab
Click "Add MCP Server"
Use the configuration below based on your operating system

Note: Make sure Claude Desktop is running before attempting to connect.

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

Setting up with Windsurf

Open Windsurf's preferences
Go to the Integrations section
Click "Add MCP Integration"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

Setting up with Cline

Open Cline's settings
Navigate to the Integrations section
Click "Add MCP Server"
Copy and paste the configuration below based on your operating system

Note: Make sure to restart Cline after adding the configuration.

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

Setting up with Goose

Open Goose's preferences
Go to the Integrations tab
Select "MCP Servers"
Click "Add New Server"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

From the repository

Install the server with uv tool install ./mcp-server (or pip install ./mcp-server), then run justfill-mcp login to authorize once. Configure your MCP client with "command": "justfill-mcp". Alternatively, set the JUSTFILL_API_KEY environment variable or use JUSTFILL_EMAIL/JUSTFILL_PASSWORD as fallback. Tools include open_pdf, render_preview, fill_pdf, save_template, and field editing tools.

Claude Desktop / Cursor

Paste into your MCP client config file to install this server.

{
    "mcpServers": {
        "justfill pdf forms": {
            "justfill": {
                "command": "uvx",
                "args": [
                    "justfill-mcp"
                ]
            }
        }
    }
}

McpServers

{
    "justfill": {
        "command": "uvx",
        "args": [
            "justfill-mcp"
        ]
    }
}

Fill existing PDF forms from JSON, Excel, or CSV with reviewed field mappings via MCP.

Let AI agents (Claude, ChatGPT, n8n — any MCP client) detect, review and fill PDF form fields throughjustfill.app.

If the source data is already in a spreadsheet and you need one filled copy of the same existing PDF per row, an MCP client is optional. The guided browser workflow imports XLSX or CSV, maps columns to reviewed PDF fields, previews each record, and exports the approved PDFs in a ZIP.

Try the five-row PDF mail merge sample— no card or sales call.

Start with the free reviewed template in the official n8n workflow catalog. It collects a PDF and JSON payload, reuses the reviewed field names saved for that exact form, fills the original layout and returns a temporary download link.

The repository also includes the exact deterministic workflow JSON, synthetic test PDF, production evidence and a separate two-pass vision workflow for an unfamiliar form. Both call the hosted MCP endpoint with standard HTTP Request nodes and can be inspected before adding credentials.

Inspect the source workflows and evidence, or follow the step-by-step n8n setup.

Install the same reviewed MCP tools plus the included PDF workflow guidance:

gemini extensions install https://github.com/mrmaciej1/justfill-mcp

The extension manifest lives at the repository root and uses the publishedjustfill-mcppackage. Gemini CLI asks for normal third-party extension consent before enabling it.

ML confidence iscalibrated: the detector's raw scores are not probabilities (its server-side filter accepts boxes from raw ~0.02 and auto-accepts at raw 0.15), so they are mapped onto 0–1 to mean what you'd expect — ≥0.75 "detector is sure", 0.4–0.75 "probably right, glance at the preview", <0.4 "borderline accept, verify". The raw detector score is kept on each field asraw_score.

The correction loop (render_preview→add/update/remove_field) exists precisely because ML detection has false positives and negatives. A false positive costs nothing (leave it unfilled or remove it); a false negative is visible on the preview and fixable with oneadd_fieldcall. Once reviewed,save_templatemakes every future fill of that form deterministic.

Authorize once (opens the browser, one click while logged in to justfill.app):

Then the config needs no credentials at all:

{ "mcpServers": { "justfill": { "command": "justfill-mcp" } } }

For a zero-install configuration, useuvxdirectly:

{ "mcpServers": { "justfill": { "command": "uvx", "args": ["justfill-mcp"] } } }

Alternatives, in the order the server checks them:
- JUSTFILL_API_KEYenv — create a key at justfill.app → Account → API Keys and put"env": {"JUSTFILL_API_KEY": "jf_live_…"}in the config.
- The key saved byjustfill-mcp login(~/.config/justfill/credentials.json).
- JUSTFILL_EMAIL+JUSTFILL_PASSWORD— legacy fallback; an API key is better (no password in config files, revocable per client, never expires mid-session).

- open_pdf(path, min_confidence=0.0, max_pages=10, force_detect=False)— template → AcroForm → ML resolution order. Accepts scanned images too (jpg/png/tiff → converted to PDF, deterministically, so templates still match).force_detect=Trueignores a saved template and re-runs ML.
- render_preview(page_index)— page image with labeled field boxes (blue = deterministic, green/orange/red = ML confidence)
- render_filled_preview(values, page_index)— the same page with your values drawn in place (checkboxes get an X). Costs no fills — check before you fill.
- list_fields(page_index?)
- add_field(x, y, w, h, name, page_index, field_type, align?, vertical_align?)— coords in % of page, top-left origin
- update_field(field_id, …)/remove_field(field_id)
- update_fields([{field_id, …}, …])/remove_fields([ids])— batch versions
- prune_fields(field_type?, confidence_below?, width_below?, height_below?, page_index?, exclude_ids?)— bulk-delete detection noise in one call (criteria AND-ed, removed ids returned)
- fill_pdf(values, output_path, flatten=True)—values={field_id: text}; responds withwarningsfor values that will be shrunk/truncated to fit
- save_template(name)— persist the reviewed layout for deterministic repeat fills
- list_templates()

Text alignment:align=left|center|right,vertical_align=top|middle|bottom— set per field (e.g.rightfor RTL forms,centerfor boxed digits). Persisted in templates.

open_pdf("~/forms/w-9.pdf") → acroform, 27 fields, confidence 1.0 fill_pdf({"f1": "Jane Doe", …}, "~/out/w-9-filled.pdf")

open_pdf("~/forms/scan.jpg") → converted to PDF; ml, 34 fields render_preview(0) → agent sees noise + one missed line prune_fields(field_type="cell", width_below=3) → 16 removed in one call add_field(x=18, y=62.5, w=40, h=3, name="Phone") render_filled_preview({…}) → values sit right, no overflow fill_pdf({…}, "~/out/filled.pdf") save_template("Client intake form") → next time: deterministic

- Auth is a regular justfill.app account; tokens auto-refresh on expiry.
- Usage and document-output rules are enforced by the same account service as the web app.fill_pdfreports whether the output is clean or watermarked.
- One PDF open at a time per server session (by design — keeps ids stable).
- This repository mirrors released versions of the MCP client (development happens in a private monorepo alongside the justfill.app backend). Bug reports and feature requests are very welcome in the issue tracker here.
