Globestudio

Open-source dotted maps and animated 3D globes for designers, animators, and creative developers.

<a href="https://globestudio.app"></a>

Pick a country or the whole world, customize dots and shapes, apply shader effects, and export PNG, SVG, or animated WebM. Built on React + Three.js.

globestudio.app · Live demos · Roadmap · Discussions

</div>

---

Why Globestudio?

Most open-source map tooling is built for engineers — tile servers, geocoding,
GIS data pipelines. Globestudio is built for the other half of the stack:
the landing-page hero shot, the launch teaser, the explainer scrollytell, the
deck slide that needs a globe but not a database.

Think of it as a Shader Lab for maps and globes — a designer-first canvas
with presets, effects, motion, and clean exports. Composable, web-native, and
yours to remix.

Features

- 🌍 Maps for any scope — world, country, continent, subregion, US state
- 🔄 Flat ↔ 3D globe — same dot data, two views, smooth morph
- 🎨 12 dot shapes + custom upload — Circle · Hexagon · Triangle · Pentagon ·
Square · Diamond · Star · Plus · Ring · Voxel · Particle Grid · ASCII glyphs ·
your own SVG/PNG
- 🪄 21 shader looks — Halftone, Risograph, Newsprint, Aurora, Pixel,
Bayer, Atkinson, Wireframe, CRT, Glitch, Bad TV, Bloom, Metal, Iridescent,
Pencil, Corrupt, Toon, Threshold, Vapor, Topographic — plus the base
Default. Stackable on any preset.
- 🌈 Gradients + alpha on dot color, land fill, and country stroke
- ✨ Live animations — rotation, twinkle, size jitter, network arcs,
motion-aware (respects prefers-reduced-motion)
- 🎛️ 21 curated presets — every shader look is a one-click preset with
matching backgrounds, density, dot size, and globe chrome. Shareable
URLs at /looks/:id.
- 💾 Real exports — PNG (high-res via WebGL re-render), SVG (with shader
effects baked in), WebM video (looped or one-shot), JSON config
- ⌨️ Full keyboard system — S shuffle, [/] cycle presets, D export,
R reset, G toggle view, H toggle panel, ? help
- ♿ Accessibility — WCAG 2.2 AA conformant. Keyboard-first, screen-
reader proxy DOM for canvas state, focus trap on modals, motion
preferences honored. See ACCESSIBILITY.md

Quickstart

Use it

The live tool runs entirely client-side:

→ globestudio.app

Pick a country, tweak the look, export.

Run it locally

Requires Node 20+ and npm.

git clone https://github.com/alevizio/globestudio
cd globestudio
npm install
npm run dev

Open http://127.0.0.1:5173/.

Build it

npm run build      # → dist/
npm run preview    # serve dist/ locally
npm test -- --run  # 173 tests across 26 files
npm run test:e2e   # browser smoke + accessibility checks

Embed it anywhere

Globestudio ships two embed paths — pick whichever fits the tool:

One-line script tag (Recommended)

<div data-globestudio data-look="halftone" data-density="50"
     style="width: 100%; height: 480px;"></div>
<script async src="https://globestudio.app/embed.js"></script>

~3kb gzipped, zero dependencies, works in Webflow / Squarespace / blog
posts / anywhere HTML is allowed. Every embed param has a matching
data-* attribute. Watches the DOM for later-added elements via
MutationObserver, so SPAs and dynamic content work too.

Plain iframe

<iframe
  src="https://globestudio.app/embed?look=halftone&density=70&autoSpin=1"
  width="100%"
  height="500"
  style="border:0"
  loading="lazy"
  title="Globestudio dotted globe"
></iframe>

Resize-aware via postMessage — listen for
{ type: "globestudio-resize", height } from the embed and resize the
iframe to match. WebGL required; falls back to a still preview + a
"how to enable WebGL" panel if the GL context can't be created.

Embed parameters

The canonical parameter table. Every query param the /embed route honors,
as parsed in src/components/embed-view.jsx:

| Param | Type / range | Default | What it does |
|---|---|---|---|
| look | preset id (one of the 21 looks) | default | Base look preset — params below override it |
| selection | world · country:<ISO3> · continent:<Name> · subregion:<Name> | world | What geography to draw |
| density | number, 1–90 | 40 | Dot grid density (invalid values fall back to the preset's) |
| dotSize | number, 0.1–25 | 10 | Dot size (invalid values fall back to the preset's) |
| dotColor | hex, # optional | preset's | Dot color |
| worldFill | hex, # optional | preset's | Land fill color |
| renderMode | dots · solid | preset's | Dot field or solid landmass |
| motion | number, 0–100 | 35 | Parsed but currently inert — reserved, no effect yet |
| tiltX | number, −45 to 45 | 0 | Camera tilt, degrees |
| tiltY | number, −45 to 45 | 0 | Camera tilt, degrees |
| autoSpin | 1 · 0 | 1 | Auto-rotate the globe |
| static | 1 · 0 | 0 | Freeze all motion (static previews in design-tool canvases) |
| view | globe · flat | globe | 3D globe or flat map |
| background | hex, # optional | unset | Page background behind the canvas (only painted when set) |
| theme | dark · light | dark | Globe chrome palette — light reads cleanly on light host pages |
| transparent | 1 · 0 | 0 | See-through document, composites onto the host page |
| plugin | figma | unset | Host-plugin shell (the Figma plugin's Insert button) |
| source | string | embed | Analytics tag, echoed in resize postMessages |
| c | URL-encoded config JSON | unset | Full share-config payload (what the Share dialog produces) — overrides the preset and the params above |

A JSON Schema for the c payload lives at
/schema/config.json.

Per-tool integration guides live at
globestudio.app/integrations —
copy-paste setups for Webflow, Framer, Figma, Notion, WordPress, plain
HTML, and React. In this repo:
Figma plugin ·
WordPress plugin ·
Framer component ·
embed snippet

Reading material:
How to make a dotted world map in 2026 ·
All articles →

Use it from AI tools (MCP)

Globestudio ships a Model Context Protocol
server, so Claude, Cursor, and any MCP-compatible assistant can generate
globes, build share URLs, and grab embed snippets straight from a chat:

claude mcp add globestudio -- npx -y @globestudio/mcp

Full tool list and setup in packages/mcp/README.md.

What you can build with it

| Use case | What it gives you |
|---|---|
| Landing page hero | A live animated globe behind your headline. Export PNG for static, WebM for video. |
| Launch teaser | Animated dot map of where your users are. WebM ready for X/LinkedIn. |
| Deck visuals | Per-country SVGs that drop straight into Keynote, Figma, or print layouts. |
| Data story | Hand-picked region + dot palette for a feature, blog post, or report. |
| Brand system | A consistent dotted-globe mark across your site, app, and docs. |
| Stream / podcast graphic | Looping WebM background with the CRT or Glitch preset. |

Runnable examples

The examples/ directory holds 9 reference projects —
runnable HTML, drop-in components, and adaptation guides. Highlights:

- embed-snippet — the minimum-viable iframe
pattern. Copy into Webflow, Framer, Notion, plain HTML, anywhere.
- hero-globe — full-bleed animated globe behind
a landing-page hero.
- shader-presets-showcase — the
shader presets in one auto-fit gallery, perfect for picking a look.

Share what you make in Show & Tell.

Documentation

| | |
|---|---|
| CONTRIBUTING | Local setup, project shape, design rules, how to submit presets/examples |
| ROADMAP | What's shipped, what's next, what's parked |
| CHANGELOG | What changed and when |
| GOVERNANCE | How decisions get made |
| CODE_OF_CONDUCT | Community standards |
| SECURITY | Reporting vulnerabilities |
| SUPPORT | Where to ask questions |

How it compares

There's no shortage of map and globe tools — Globestudio doesn't try
to replace any of them. It owns the aesthetic-asset shelf: stylized
output that ships to a landing page hero, deck slide, OG card, or
launch teaser. Different tools for different jobs:

| | Globestudio | globe.gl | Mapbox Studio | Felt | Haikei |
|---|---|---|---|---|---|
| 3D globe out of box | ✅ | ✅ | ❌ | ❌ | ❌ |
| Dotted maps | ✅ 12 shapes | partial | ❌ | ❌ | ❌ |
| Shader aesthetic looks | ✅ 21 | ❌ | custom WebGL only | ❌ | ❌ |
| Multiple projections | 5 | sphere only | many | many | n/a |
| No-code GUI | ✅ | ❌ library | ✅ | ✅ | ✅ |
| PNG / SVG / WebM export | ✅ | manual | print / PDF | ✅ | PNG / SVG |
| Embed iframe | ✅ /embed | DIY | ✅ | ✅ | DIY |
| Framer / Webflow components | ✅ | ❌ | plugins | ❌ | ❌ |
| No signup / no API key | ✅ | n/a | ❌ | ❌ | ✅ |
| Free + MIT | ✅ | ✅ (library) | freemium | paid | free, closed |

What Globestudio gives up: GIS-accurate data overlays, large dataset
analysis, real-time collaboration. If those are what you need, reach
for Mapbox / Felt / Kepler — they're great at them.

Built on the shoulders of: globe.gl
and COBE defined what a modern OSS
3D globe library looks like. dotted-map
is the engine under the dot field. Stamen Maps
was the spiritual ancestor of "maps as visual aesthetic."

Tech stack

Built with:

- React 19 + Vite for the app shell
- Three.js for the WebGL globe, instanced dot rendering, shader effects, network arcs
- dotted-map for the source dot field
- d3-geo + d3-geo-projection + topojson-client for projections (Mercator, Equirectangular, Equal Earth, Winkel Tripel, Robinson) and topology decoding
- world-countries + world-atlas + us-atlas for source geography
- satori + @resvg/resvg-js for the OG share card pipeline (JSX → SVG → PNG at build time)
- Pixelarticons by Gerrit Halfmann for the in-app icon set — 24×24 pixel-grid icons with currentColor fill so they theme cleanly
- Vitest + Testing Library + axe-core for tests and the WCAG 2.2 AA accessibility guard

No backend and no accounts. Privacy-respecting Vercel Analytics and Speed
Insights honor Do Not Track, Global Privacy Control, and the local opt-out in
/privacy; everything else renders in your browser.

Contributing

We want contributions. Code, presets, example projects, screenshots, docs
rewrites — all of it counts.

The shortest path:

1. Build something cool with the live tool → drop it in
Show & Tell
2. Found a bug? → Bug report
3. Made a preset you love? → Preset submission
4. Have an idea? → Ideas discussion

Full guide in CONTRIBUTING.md.

License

MIT. Use it, remix it, ship it. If you use it commercially or
prominently we'd love to hear about it (no obligation, just curious).

The included geography data comes from
world-atlas,
us-atlas, and
world-countries — all with permissive
licenses. If you build on top of derived map data outside this repo,
double-check the source attributions.

---
