A server to interact with FreeCAD models using the Model Context Protocol (MCP).

Details

Author: neka-nat
GitHub stars: 1,254
Downloads: 2,530
Categories: Developer Tools, Other

- Create, edit, and delete FreeCAD objects via natural language
- Execute arbitrary Python code in FreeCAD’s environment
- Insert parts from the FreeCAD parts library
- Capture screenshots of the active 3D view
- Run CalculiX FEM analysis and retrieve summary results
- Support for remote connections over a network
- Auto-start RPC server on FreeCAD launch

Setting up with Highlight

This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:

Download and install Highlight from highlightai.com/download
Navigate to the plugins tab and select "Add Custom Plugin"
Configure the plugin with the settings below

Plugin Name FreeCAD MCP

Command (node, npx, python, etc.)

Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
Enable "Start Automatically" if you want the plugin to start when Highlight launches

Setting up with Cursor

Open Cursor's settings
Navigate to the MCP section
Click "Add new Global MCP server"
Copy and paste the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

Setting up with Claude Desktop

Open Claude Desktop's settings
Go to the Integrations tab
Click "Add MCP Server"
Use the configuration below based on your operating system

Note: Make sure Claude Desktop is running before attempting to connect.

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

Setting up with Windsurf

Open Windsurf's preferences
Go to the Integrations section
Click "Add MCP Integration"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

Setting up with Cline

Open Cline's settings
Navigate to the Integrations section
Click "Add MCP Server"
Copy and paste the configuration below based on your operating system

Note: Make sure to restart Cline after adding the configuration.

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

Setting up with Goose

Open Goose's preferences
Go to the Integrations tab
Select "MCP Servers"
Click "Add New Server"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

From the repository

Install the FreeCAD MCP addon by copying the addon/FreeCADMCP directory to your FreeCAD Mod folder (paths differ by OS). Then restart FreeCAD, switch to the “MCP Addon” workbench, and click “Start RPC Server” in the toolbar. Configure Claude Desktop by editing claude_desktop_config.json to use uvx freecad-mcp as the MCP server command. Optionally enable auto-start of the RPC server via the FreeCAD MCP menu, or set up remote connections with --host and allowed IPs.

Claude Desktop / Cursor

Paste into your MCP client config file to install this server.

{
    "mcpServers": {
        "freecad mcp": {
            "freecad": {
                "command": "uvx",
                "args": [
                    "freecad-mcp"
                ]
            }
        }
    }
}

McpServers

{
    "freecad": {
        "command": "uvx",
        "args": [
            "freecad-mcp"
        ]
    }
}

This repository is a FreeCAD MCP that allows you to control FreeCAD from Claude Desktop.

This is the conversation history.https://claude.ai/share/7b48fd60-68ba-46fb-bb21-2fbb17399b48

- Windows:%APPDATA%\FreeCAD\Mod\
- Mac:

- FreeCAD 1.1:~/Library/Application\ Support/FreeCAD/v1-1/Mod/
- FreeCAD 1.0:~/Library/Application\ Support/FreeCAD/v1-0/Mod/

- Ubuntu:~/.FreeCAD/Mod/or~/snap/freecad/common/Mod/(if you install FreeCAD from snap)
- Debian:~/.local/share/FreeCAD/Mod
- Arch / CachyOS (FreeCAD 1.1 fromextra/freecad):~/.local/share/FreeCAD/v1-1/Mod/
- Flatpak:~/.var/app/org.freecad.FreeCAD/data/FreeCAD/v1-1/Mod/

Please putaddon/FreeCADMCPdirectory to the addon directory.

git clone https://github.com/neka-nat/freecad-mcp.git cd freecad-mcp # For Linux (Ubuntu/Debian) mkdir -p ~/.FreeCAD/Mod/ cp -r addon/FreeCADMCP ~/.FreeCAD/Mod/ # For Linux (Arch/CachyOS, FreeCAD 1.1 from extra/freecad) mkdir -p ~/.local/share/FreeCAD/v1-1/Mod/ cp -r addon/FreeCADMCP ~/.local/share/FreeCAD/v1-1/Mod/ # For Linux (Flatpak) mkdir -p ~/.var/app/org.freecad.FreeCAD/data/FreeCAD/v1-1/Mod/ cp -r addon/FreeCADMCP ~/.var/app/org.freecad.FreeCAD/data/FreeCAD/v1-1/Mod/ # For macOS (FreeCAD 1.1) mkdir -p ~/Library/Application\ Support/FreeCAD/v1-1/Mod/ cp -r addon/FreeCADMCP ~/Library/Application\ Support/FreeCAD/v1-1/Mod/

When you install addon, you need to restart FreeCAD. You can select "MCP Addon" from Workbench list and use it.

And you can start RPC server by "Start RPC Server" command in "FreeCAD MCP" toolbar.

By default, the RPC server must be started manually each time FreeCAD opens. To start it automatically:
- Open theFreeCAD MCPmenu (switch to the MCP Addon workbench first)
- CheckAuto-Start Server

The setting is saved tofreecad_mcp_settings.jsonand persists across sessions. On the next FreeCAD launch, the RPC server will start automatically once the application finishes loading.

You can disable it at any time by uncheckingAuto-Start Serverin the same menu.

Pre-installation of the uvxis required.

And you need to edit Claude Desktop config file,claude_desktop_config.json.

{ "mcpServers": { "freecad": { "command": "uvx", "args": [ "freecad-mcp" ] } } }

If you want to save token, you can setonly_text_feedbacktotrueand use only text feedback.

{ "mcpServers": { "freecad": { "command": "uvx", "args": [ "freecad-mcp", "--only-text-feedback" ] } } }

Screenshots can also be controlled per tool call instead of globally: every tool that returns a screenshot accepts an optionalinclude_screenshotparameter (passfalseto get text-only feedback, e.g. for analytical scripts or intermediate steps) and an optionalview_nameparameter to orient the screenshot ("Isometric" by default, or "Front", "Top", "Right", etc.). The--only-text-feedbackflag always wins: when it is set, no screenshots are returned regardless ofinclude_screenshot.

For developer. First, you need clone this repository.

git clone https://github.com/neka-nat/freecad-mcp.git

{ "mcpServers": { "freecad": { "command": "uv", "args": [ "--directory", "/path/to/freecad-mcp/", "run", "freecad-mcp" ] } } }

By default the RPC server does not accept remote connections and listens onlocalhost. To control FreeCAD from another machine on your network:
-

CheckRemote Connections— the RPC server will bind to0.0.0.0(all interfaces) on the next restart. For security reasons, it only accepts connections from the IP addresses or CIDR subnets specified in theAllowed IPsfield. By default this is127.0.0.1.

ClickConfigure Allowed IPsand enter a comma-separated list of IP addresses or CIDR subnets that are allowed to connect, e.g.:

127.0.0.1is always the default. Invalid entries are rejected with an error dialog. Restart the RPC server after changing these settings.

2. Point the MCP server at the remote host

Pass the--hostflag with the IP address or hostname of the machine running FreeCAD:

{ "mcpServers": { "freecad": { "command": "uvx", "args": [ "freecad-mcp", "--host", "192.168.1.100" ] } } }

The--hostvalue is validated on startup — it must be a valid IPv4/IPv6 address or hostname.

- create_document: Create a new document in FreeCAD.
- create_object: Create a new object in FreeCAD.
- edit_object: Edit an object in FreeCAD.
- delete_object: Delete an object in FreeCAD.
- execute_code: Execute arbitrary Python code in FreeCAD.
- insert_part_from_library: Insert a part from theparts library.
- get_view: Get a screenshot of the active view.
- get_objects: Get all objects in a document.
- get_object: Get an object in a document.
- get_parts_list: Get the list of parts in the parts library.
- get_rpc_status: Report RPC and GUI-dispatch health without using the FreeCAD GUI thread.
- run_fem_analysis: Run the CalculiX solver on an existingFem::FemAnalysisand return summary results (max von Mises stress, max displacement, node count, working directory). Auto-creates aSolverCcxToolsif the analysis has none. See examples/cantilever_fem.pyfor an end-to-end usage example.

Tools that return a screenshot (create_object,edit_object,delete_object,execute_code,insert_part_from_library,get_objects,get_object,run_fem_analysis) accept optionalinclude_screenshot(defaulttrue) andview_name(default"Isometric") parameters to suppress or reorient the returned image per call.

If a GUI-thread operation exceeds its timeout after it has started, the bridge returnsGUI_DISPATCH_STUCKand rejects later GUI operations immediately. Useget_rpc_statusto identify the operation that is still running. FreeCAD GUI work cannot be force-cancelled safely; if the status does not return tohealthyafter the operation finishes, restart FreeCAD.

After anexecute_codeexception on a FreeCAD development build, inspect any newFeaturePythonobject before mutating or deleting it. In particular, do not continue with an object whose requiredProxywas never installed, as touching that broken object can wedge FreeCAD's GUI thread.
