Editor Mcp Server

by playcanvas

120 stars

572 downloads

Not rated

GitHub

Other

About

MCP Server for AI automation of the PlayCanvas Editor

Details

Author: playcanvas
GitHub stars: 120
Downloads: 572
Categories: Other

- 30+ tools covering entities, assets, scene settings, viewport, and runtime
- Live runtime control: launch, capture, read logs, and inject input
- Consistent response envelope with pagination and error reporting
- Read-only, destructive, and open-world tool annotations for safe LLM use
- Chrome extension connects the PlayCanvas Editor to the MCP server

Setting up with Highlight

This MCP is not yet compatible with Highlight’s one-click setup. However, you can still use it with Highlight by following these steps:

Download and install Highlight from highlightai.com/download
Navigate to the plugins tab and select "Add Custom Plugin"
Configure the plugin with the settings below

Plugin Name Editor Mcp Server

Command (node, npx, python, etc.)

Please refer to the README for specific instructions on how to obtain API keys or other required environment variables.
Enable "Start Automatically" if you want the plugin to start when Highlight launches

Setting up with Cursor

Open Cursor's settings
Navigate to the MCP section
Click "Add new Global MCP server"
Copy and paste the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

Setting up with Claude Desktop

Open Claude Desktop's settings
Go to the Integrations tab
Click "Add MCP Server"
Use the configuration below based on your operating system

Note: Make sure Claude Desktop is running before attempting to connect.

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

Setting up with Windsurf

Open Windsurf's preferences
Go to the Integrations section
Click "Add MCP Integration"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

Setting up with Cline

Open Cline's settings
Navigate to the Integrations section
Click "Add MCP Server"
Copy and paste the configuration below based on your operating system

Note: Make sure to restart Cline after adding the configuration.

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

Setting up with Goose

Open Goose's preferences
Go to the Integrations tab
Select "MCP Servers"
Click "Add New Server"
Use the configuration below based on your operating system

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

JSON

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

From the repository

Install dependencies with npm install, load the Chrome extension (unpacked from the extension folder), then run npx tsx src/server.ts with a PORT env variable (default 52000). In the PlayCanvas Editor tab, open the extension popup and click CONNECT. Configure the MCP server in Claude Desktop or Cursor using the provided JSON config. Cursor users must select Agent mode.

Claude Desktop / Cursor

Paste into your MCP client config file to install this server.

{
    "mcpServers": {
        "editor mcp server": {
            "playcanvas": {
                "command": "cmd",
                "args": [
                    "/c",
                    "npx",
                    "tsx",
                    "C:\\path\\to\\mcp-editor\\src\\server.ts"
                ],
                "env": {
                    "PORT": "52000"
                }
            }
        }
    }
}

McpServers

{
    "playcanvas": {
        "command": "cmd",
        "args": [
            "/c",
            "npx",
            "tsx",
            "C:\\path\\to\\mcp-editor\\src\\server.ts"
        ],
        "env": {
            "PORT": "52000"
        }
    }
}

██████╗ ██╗ █████╗ ██╗ ██╗ ██████╗ █████╗ ███╗ ██╗██╗ ██╗ █████╗ ███████╗
██╔══██╗██║ ██╔══██╗╚██╗ ██╔╝██╔════╝██╔══██╗████╗ ██║██║ ██║██╔══██╗██╔════╝
██████╔╝██║ ███████║ ╚████╔╝ ██║ ███████║██╔██╗ ██║██║ ██║███████║███████╗
██╔═══╝ ██║ ██╔══██║ ╚██╔╝ ██║ ██╔══██║██║╚██╗██║╚██╗ ██╔╝██╔══██║╚════██║
██║ ███████╗██║ ██║ ██║ ╚██████╗██║ ██║██║ ╚████║ ╚████╔╝ ██║ ██║███████║
╚═╝ ╚══════╝╚═╝ ╚═╝ ╚═╝ ╚═════╝╚═╝ ╚═╝╚═╝ ╚═══╝ ╚═══╝ ╚═╝ ╚═╝╚══════╝

███╗ ███╗ ██████╗██████╗ ███████╗███████╗██████╗ ██╗ ██╗███████╗██████╗
████╗ ████║██╔════╝██╔══██╗ ██╔════╝██╔════╝██╔══██╗██║ ██║██╔════╝██╔══██╗
██╔████╔██║██║ ██████╔╝ ███████╗█████╗ ██████╔╝██║ ██║█████╗ ██████╔╝
██║╚██╔╝██║██║ ██╔═══╝ ╚════██║██╔══╝ ██╔══██╗╚██╗ ██╔╝██╔══╝ ██╔══██╗
██║ ╚═╝ ██║╚██████╗██║ ███████║███████╗██║ ██║ ╚████╔╝ ███████╗██║ ██║
╚═╝ ╚═╝ ╚═════╝╚═╝ ╚══════╝╚══════╝╚═╝ ╚═╝ ╚═══╝ ╚══════╝╚═╝ ╚═╝

An MCP Server for automating the PlayCanvas Editor using an LLM.

Screenshot 2025-03-21 at 15 50 10

> [!IMPORTANT]
> At the moment, the MCP Server needs to be driven by Anthropic's Claude. Our experience shows that the free tier for Claude does not deliver a big enough chat context to operate the MCP Server reliably. Therefore, we strongly recommend subscribing to a Pro Claude account.

Available Tools

Entity
list_entities
resolve_entities
create_entities
delete_entities
duplicate_entities
modify_entities
reparent_entity
add_components
remove_components
add_script_component_script
attach_script
Asset
list_assets
create_assets
delete_assets
instantiate_template_assets
set_script_text
script_parse
set_material_diffuse
set_material_properties
Scene
query_scene_settings
modify_scene_settings
Store
store_search
store_get
store_download
Viewport
capture_viewport
focus_viewport
Runtime (live Launch instance)
launch_start
launch_stop
capture_runtime
read_runtime_logs
inject_input

Runtime Tools

The runtime tools drive a real Launch instance (the editor's Launch button) so
you can verify that a scene actually runs, not just how it looks at edit time:

launch_start opens https://launch.playcanvas.com/<sceneId>?debug=true in a new
window. The extension injects a content script there that connects back to the MCP
server as the "runtime" peer. launch_start returns { url, sceneId, ready }.
capture_runtime screenshots the running app (scripts/physics/animation active).
read_runtime_logs returns the app's console output + uncaught
exceptions/rejections (newest first, paginated; defaults to warnings + errors).
inject_input dispatches keyboard / mouse / touch events to the running app
(e.g. hold W for 500ms, click at a canvas coordinate, tap the screen), so you
can drive end-to-end interactions and then verify with capture_runtime.
launch_stop closes the launch window.

Notes:

Allow pop-ups for the editor origin, otherwise launch_start cannot open the window.
The launch page uses your existing PlayCanvas login session (same browser), so no
extra auth step is needed.
Reload the unpacked extension in chrome://extensions/ after updating it so the new
launch content script + permissions take effect.

Response Format

Every tool returns a single, consistent envelope so agents can pattern-match on a stable shape:

{ "data": <result> | null, // business payload; an empty set is [], never an error "meta": { "tool": "entities:list", "status": "ok" | "error", "message": "...", // present only on error; actionable, with a recovery hint // list tools also include pagination metadata: "total": 120, "count": 50, "hasMore": true, "nextCursor": "50" } }

Notes for tool authors / agents:

Errors never use a top-level error field; they set meta.status = "error" and put an actionable message in meta.message (the protocol-level isError flag is also set).
Empty results (list_, resolve_entities) are a successful empty list, not an error.
Pagination: list_entities / list_assets accept limit (default 50) + offset. Page using meta.nextCursor (pass it back as offset) and stop when meta.hasMore is false.
State snapshots: mutating tools (create_entities, modify_entities, add_components, reparent_entity, duplicate_entities, instantiate_template_assets, …) return the resulting entity/asset summaries — including a human-readable hierarchy path — so you rarely need a follow-up list_entities call.
Annotations: read-only tools declare readOnlyHint, destructive tools (delete_) declare destructiveHint, and store tools declare openWorldHint (they reach the network).

Image tools (capture_viewport) return a protocol image block plus a parallel text block carrying the same meta.

Installation

Run npm install to install all dependencies.

Install Chrome Extension

1. Visit chrome://extensions/ and enable Developer mode
2. Click Load unpacked and select the extension folder
3. Load the PlayCanvas Editor. The extension should be loaded.

Run MCP Server

The MCP Server can be driven by Cursor or Claude Desktop.

> [!TIP]
> We have found Claude Desktop to be generally more reliable.

Claude Desktop

1. Install Claude Desktop.
2. Go to Claude > Settings.
3. Select Developer and then Edit Config.
4. This will open claude_desktop_config.json, your MCP Config JSON file.

Cursor

1. Install Cursor.
2. Select File > Preferences > Cursor Settings.
3. Click + Add new global MCP server.
4. This will open mcp.json, your MCP Config JSON file.

> [!TIP]
> Also in Cursor Settings, select Features and scroll to the Chat section. Activate Enable auto-run mode to allow the LLM to run MCP tools without requiring constant authorization. You do this at your own risk (but we prefer it)!

> [!IMPORTANT]
> In Cursor, ensure you have Agent selected. Ask and Edit modes will not recognize the MCP Server.

MCP Config JSON File

This is how your config should look:

Windows

{
  "mcpServers": {
    "playcanvas": {
      "command": "cmd",
      "args": [
        "/c",
        "npx",
        "tsx",
        "C:\\path\\to\\editor-mcp-server\\src\\server.ts"
      ],
      "env": {
        "PORT": "52000"
      }
    }
  }
}

macOS

{
  "mcpServers": {
    "playcanvas": {
      "command": "npx",
      "args": [
        "tsx",
        "/path/to/editor-mcp-server/src/server.ts"
      ],
      "env": {
        "PORT": "52000"
      }
    }
  }
}

Connecting the Editor to the MCP Server

The PlayCanvas Editor does not connect to the MCP Server automatically. To connect:

1. Activate a Chrome tab running the PlayCanvas Editor.
2. Select the Extensions icon to the right of the address bar.
3. Select PlayCanvas Editor MCP Extension to open the extension popup.
4. Select CONNECT (the port number should match what is set in your MCP Config JSON File).

> [!NOTE]
> You can currently only connect one instance of the PlayCanvas Editor to the MCP Server at any one time.

You should now be able to issue commands in Claude Desktop or Cursor.
