MCP Server Chart

A Model Context Protocol server for generating charts using AntV. We can use this mcp server for _chart generation_ and _data analysis_.

This is a TypeScript-based MCP server that provides chart generation capabilities. It allows you to create various types of charts through MCP tools. You can also use it in Dify.

📋 Table of Contents

- ✨ Features
- 🤖 Usage
- 🎨 Skill Usage
- 🚰 Run with SSE or Streamable transport
- 🎮 CLI Options
- ⚙️ Environment Variables
- VIS_REQUEST_SERVER
- SERVICE_ID
- DISABLED_TOOLS
- 📠 Private Deployment
- 🗺️ Generate Records
- 🎛️ Tool Filtering
- 🔨 Development
- 📄 License

✨ Features

Now 26+ charts supported.

1. generate_area_chart: Generate an area chart, used to display the trend of data under a continuous independent variable, allowing observation of overall data trends.
1. generate_bar_chart: Generate a bar chart, used to compare values across different categories, suitable for horizontal comparisons.
1. generate_boxplot_chart: Generate a boxplot, used to display the distribution of data, including the median, quartiles, and outliers.
1. generate_column_chart: Generate a column chart, used to compare values across different categories, suitable for vertical comparisons.
1. generate_district_map - Generate a district-map, used to show administrative divisions and data distribution.
1. generate_dual_axes_chart: Generate a dual-axes chart, used to display the relationship between two variables with different units or ranges.
1. generate_fishbone_diagram: Generate a fishbone diagram, also known as an Ishikawa diagram, used to identify and display the root causes of a problem.
1. generate_flow_diagram: Generate a flowchart, used to display the steps and sequence of a process.
1. generate_funnel_chart: Generate a funnel chart, used to display data loss at different stages.
1. generate_histogram_chart: Generate a histogram, used to display the distribution of data by dividing it into intervals and counting the number of data points in each interval.
1. generate_line_chart: Generate a line chart, used to display the trend of data over time or another continuous variable.
1. generate_liquid_chart: Generate a liquid chart, used to display the proportion of data, visually representing percentages in the form of water-filled spheres.
1. generate_mind_map: Generate a mind-map, used to display thought processes and hierarchical information.
1. generate_network_graph: Generate a network graph, used to display relationships and connections between nodes.
1. generate_organization_chart: Generate an organizational chart, used to display the structure of an organization and personnel relationships.
1. generate_path_map - Generate a path-map, used to display route planning results for POIs.
1. generate_pie_chart: Generate a pie chart, used to display the proportion of data, dividing it into parts represented by sectors showing the percentage of each part.
1. generate_pin_map - Generate a pin-map, used to show the distribution of POIs.
1. generate_radar_chart: Generate a radar chart, used to display multi-dimensional data comprehensively, showing multiple dimensions in a radar-like format.
1. generate_sankey_chart: Generate a sankey chart, used to display data flow and volume, representing the movement of data between different nodes in a Sankey-style format.
1. generate_scatter_chart: Generate a scatter plot, used to display the relationship between two variables, showing data points as scattered dots on a coordinate system.
1. generate_treemap_chart: Generate a treemap, used to display hierarchical data, showing data in rectangular forms where the size of rectangles represents the value of the data.
1. generate_venn_chart: Generate a venn diagram, used to display relationships between sets, including intersections, unions, and differences.
1. generate_violin_chart: Generate a violin plot, used to display the distribution of data, combining features of boxplots and density plots to provide a more detailed view of the data distribution.
1. generate_word_cloud_chart: Generate a word-cloud, used to display the frequency of words in textual data, with font sizes indicating the frequency of each word.
1. generate_spreadsheet: Generate a spreadsheet or pivot table for displaying tabular data. When 'rows' or 'values' fields are provided, it renders as a pivot table (cross-tabulation); otherwise, it renders as a regular table.

> [!NOTE]
> The above geographic visualization chart generation tool uses AMap service and currently only supports map generation within China.

🤖 Usage

To use with Desktop APP, such as Claude, VSCode, Cline, Cherry Studio, Cursor, and so on, add the MCP server config below. On Mac system:

{
  "mcpServers": {
    "mcp-server-chart": {
      "command": "npx",
      "args": ["-y", "@antv/mcp-server-chart"]
    }
  }
}

On Window system:

{
  "mcpServers": {
    "mcp-server-chart": {
      "command": "cmd",
      "args": ["/c", "npx", "-y", "@antv/mcp-server-chart"]
    }
  }
}

Also, you can use it on aliyun, modelscope, glama.ai, smithery.ai or others with HTTP, SSE Protocol.

🎨 Skill Usage

If you are using an AI IDE with skill support (like Claude Code), you can use the chart-visualization skill to automatically select the best chart type and generate visualizations.

You can add the skill from https://github.com/antvis/chart-visualization-skills using:

npx skills add antvis/chart-visualization-skills

Then provide your data or describe the visualization you want. The skill will intelligently choose from 25+ chart types and generate the chart for you.

🚰 Run with SSE or Streamable transport

Run directly

Install the package globally.

npm install -g @antv/mcp-server-chart

Run the server with your preferred transport option:

```bash
