🧠 Adaptive Graph of Thoughts

<div align="center">

🚀 Next-Generation AI Reasoning Framework for Scientific Research

Leveraging graph structures to transform how AI systems approach scientific reasoning

</div>

---

🔍 Overview

Adaptive Graph of Thoughts (AGoT) is a high-performance MCP server that implements the Advanced Scientific Reasoning Graph-of-Thoughts (ASR-GoT) framework. It uses a Neo4j graph database as a dynamic knowledge store and exposes reasoning capabilities through the Model Context Protocol (MCP), enabling seamless integration with AI assistants like Claude Desktop.

Key Highlights

| Feature | Description |
|---------|-------------|
| 🧠 Graph-Based Reasoning | Multi-stage pipeline with 8 specialized reasoning stages |
| 📊 Dynamic Confidence Scoring | Multi-dimensional evaluation with uncertainty quantification |
| 🔬 Evidence Integration | Real-time connection to PubMed, Google Scholar & Exa Search |
| ⚡ High Performance | Async FastAPI with Neo4j graph operations |
| 🔌 MCP Protocol | Native Claude Desktop & VS Code integration |
| 🐳 Cloud-Ready | Full Docker + Kubernetes (Helm) support |

---

🏗️ System Architecture

%%{init: {'theme': 'base', 'themeVariables': {'primaryColor': '#4A90D9', 'primaryTextColor': '#fff', 'primaryBorderColor': '#2C5F8A', 'lineColor': '#666', 'secondaryColor': '#52B788', 'tertiaryColor': '#F8F9FA'}}}%%
graph TB
    subgraph Clients["🖥️ Client Layer"]
        CD["🤖 Claude Desktop"]
        VS["💻 VS Code / Cursor"]
        CC["🔗 Custom MCP Clients"]
    end
subgraph Gateway["🌐 API Gateway Layer"]

        MCP_EP["⚡ MCP Endpoint\n/mcp"]

        NLQ_EP["🔍 NLQ Endpoint\n/nlq"]

        GE_EP["📊 Graph Explorer\n/graph"]

        HE["💚 Health Check\n/health"]

    end
subgraph Core["🧠 Core Application Layer"]

        direction TB

        GTP["🔄 GoT Processor\nOrchestrator"]

        subgraph Pipeline["ASR-GoT 8-Stage Pipeline"]

            S1["1️⃣ Init &\nContext Setup"]

            S2["2️⃣ Query\nDecomposition"]

            S3["3️⃣ Hypothesis\nGeneration"]

            S4["4️⃣ Evidence\nIntegration"]

            S5["5️⃣ Pruning &\nMerging"]

            S6["6️⃣ Subgraph\nExtraction"]

            S7["7️⃣ Synthesis &\nComposition"]

            S8["8️⃣ Reflection &\nAudit"]

            S1 --> S2 --> S3 --> S4 --> S5 --> S6 --> S7 --> S8

        end

        GTP --> Pipeline

    end
subgraph Services["🛠️ Service Layer"]

        LLM["🤖 LLM Service\nOpenAI / Claude"]

        EDB["📚 Evidence DB\nPubMed · Scholar · Exa"]

    end
subgraph Storage["🗄️ Storage Layer"]

        NEO4J["📦 Neo4j\nGraph Database"]

        CONFIG["⚙️ Config\n(YAML + ENV)"]

    end
Clients -->|"MCP JSON-RPC\nBearer Auth"| Gateway

    MCP_EP --> GTP

    NLQ_EP --> LLM

    GE_EP --> NEO4J

    GTP --> Services

    GTP --> NEO4J

    LLM --> EDB
style Clients fill:#E3F2FD,stroke:#1565C0

    style Gateway fill:#F3E5F5,stroke:#6A1B9A

    style Core fill:#E8F5E9,stroke:#1B5E20

    style Services fill:#FFF8E1,stroke:#F57F17

    style Storage fill:#FCE4EC,stroke:#880E4F

---

🔄 ASR-GoT Reasoning Pipeline

The 8-stage reasoning pipeline transforms a raw question into a comprehensive, evidence-backed answer stored in the knowledge graph:

%%{init: {'theme': 'base', 'themeVariables': {'primaryColor': '#7B68EE', 'edgeLabelBackground': '#fff'}}}%%
flowchart LR
    Q([❓ Scientific\nQuestion]) --> S1
subgraph S1["Stage 1: Initialization"]

        I1["Set context\n& parameters"]

        I2["Create root\ngraph node"]

        I1 --> I2

    end
subgraph S2["Stage 2: Decomposition"]

        D1["Identify\nsub-questions"]

        D2["Map knowledge\ndomains"]

        D1 --> D2

    end
subgraph S3["Stage 3: Hypothesis"]

        H1["Generate\nhypotheses"]

        H2["Score initial\nconfidence"]

        H1 --> H2

    end
subgraph S4["Stage 4: Evidence"]

        E1["Query PubMed\nScholar · Exa"]

        E2["Integrate\nevidence nodes"]

        E1 --> E2

    end
subgraph S5["Stage 5: Pruning"]

        P1["Remove weak\nhypotheses"]

        P2["Merge related\nnodes"]

        P1 --> P2

    end
subgraph S6["Stage 6: Subgraph"]

        SG1["Extract key\nsubgraphs"]

        SG2["Score relevance\n& centrality"]

        SG1 --> SG2

    end
subgraph S7["Stage 7: Synthesis"]

        C1["Compose final\nnarrative"]

        C2["Build\nconclusions"]

        C1 --> C2

    end
subgraph S8["Stage 8: Reflection"]

        R1["Audit\nconsistency"]

        R2["Return final\nresult"]

        R1 --> R2

    end
S1 --> S2 --> S3 --> S4 --> S5 --> S6 --> S7 --> S8

    S8 --> A([✅ Reasoned\nAnswer])
style Q fill:#FFD700,stroke:#DAA520,color:#000

    style A fill:#90EE90,stroke:#228B22,color:#000

---

🕸️ Knowledge Graph Connectome

The Neo4j knowledge graph captures the reasoning structure as a rich connectome — nodes represent concepts, hypotheses, and evidence, while edges represent semantic and logical relationships:

%%{init: {'theme': 'base', 'themeVariables': {'primaryColor': '#6C63FF', 'primaryTextColor': '#fff', 'edgeLabelBackground': '#f0f0ff'}}}%%
graph TD
    RootQuery["🔍 Root Query\n(Session Node)"]
subgraph Decomp["📐 Decomposition Layer"]

        D1["📌 Sub-question A\n[domain: biology]"]

        D2["📌 Sub-question B\n[domain: chemistry]"]

        D3["📌 Sub-question C\n[domain: physics]"]

    end
subgraph Hypo["💡 Hypothesis Layer"]

        H1["💭 Hypothesis 1\nconf: 0.85"]

        H2["💭 Hypothesis 2\nconf: 0.72"]

        H3["💭 Hypothesis 3\nconf: 0.61"]

        H4["💭 Hypothesis 4\nconf: 0.90"]

    end
subgraph Evid["🔬 Evidence Layer"]

        E1["📄 PubMed Paper\nPMID: 38492"]

        E2["📄 Scholar Article\nDOI: 10.1038/..."]

        E3["🌐 Exa Result\nexpert consensus"]

        E4["📊 Statistical\nMeta-analysis"]

    end
subgraph Synth["🎯 Synthesis Layer"]

        C1["✅ Merged\nConclusion A"]

        C2["✅ Merged\nConclusion B"]

        FINAL["🏆 Final Answer\n[confidence: 0.88]"]

    end
RootQuery -->|"DECOMPOSES_TO"| D1

    RootQuery -->|"DECOMPOSES_TO"| D2

    RootQuery -->|"DECOMPOSES_TO"| D3
D1 -->|"GENERATES"| H1

    D1 -->|"GENERATES"| H2

    D2 -->|"GENERATES"| H3

    D3 -->|"GENERATES"| H4
H1 -->|"SUPPORTED_BY"| E1

    H2 -->|"SUPPORTED_BY"| E2

    H3 -->|"CONTRADICTED_BY"| E3

    H4 -->|"SUPPORTED_BY"| E4
H1 -->|"MERGES_WITH"| C1

    H4 -->|"MERGES_WITH"| C1

    H2 -->|"MERGES_WITH"| C2

    C1 -->|"SYNTHESIZES_TO"| FINAL

    C2 -->|"SYNTHESIZES_TO"| FINAL
style RootQuery fill:#4A90D9,color:#fff,stroke:#2C5F8A

    style FINAL fill:#27AE60,color:#fff,stroke:#1E8449

    style H3 fill:#E74C3C,color:#fff,stroke:#C0392B

---

🔁 Request Flow

%%{init: {'theme': 'base'}}%%
sequenceDiagram
    actor User as 🤖 Claude / MCP Client
    participant API as ⚡ FastAPI Server
    participant Auth as 🔐 Auth Middleware
    participant GTP as 🧠 GoT Processor
    participant NEO as 📦 Neo4j DB
    participant LLM as 🤖 LLM Service
User->>API: POST /mcp {"method": "asr_got.query"}

    API->>Auth: Verify Bearer Token

    Auth-->>API: ✅ Authorized
API->>GTP: Process query

    GTP->>NEO: Create session + root node
loop 8 Pipeline Stages

        GTP->>LLM: Generate hypotheses / summaries

        LLM-->>GTP: LLM response

        GTP->>NEO: Write nodes & relationships

        NEO-->>GTP: Confirmed

    end
GTP->>NEO: Extract final subgraph

    NEO-->>GTP: Final answer graph

    GTP-->>API: Structured result
API-->>User: JSON-RPC response\n{result, confidence, graph_state}

---

📚 Documentation

Full documentation including API reference, configuration guide, and contribution guidelines:

➡️ Adaptive Graph of Thoughts Documentation Site

📂 Project Structure

Adaptive-Graph-of-Thoughts-MCP-server/
├── 📁 .github/             # CI/CD workflows (CodeQL, Dependabot)
├── 📁 agt_setup/           # Interactive setup wizard CLI
├── 📁 config/              # settings.yaml configuration
├── 📁 docs_src/            # MkDocs documentation source
├── 📁 helm/                # Kubernetes Helm chart
├── 📁 src/
│   └── 📁 adaptive_graph_of_thoughts/
│       ├── 📁 api/         # FastAPI routes & schemas
│       ├── 📁 application/ # GoTProcessor orchestrator
│       ├── 📁 domain/      # 8-stage pipeline & models
│       ├── 📁 infrastructure/ # Neo4j utilities
│       └── 📁 services/    # LLM & external API clients
├── 📁 tests/               # Comprehensive test suite
├── Dockerfile
├── docker-compose.yml
├── pyproject.toml
└── README.md

🚀 Quick Start

git clone https://github.com/SaptaDey/Adaptive-Graph-of-Thoughts-MCP-server.git
cd Adaptive-Graph-of-Thoughts-MCP-server
poetry install
poetry run python -m agt_setup   # Interactive credential setup wizard
poetry run uvicorn adaptive_graph_of_thoughts.main:app --reload

Visit http://localhost:8000/docs for the interactive API documentation.

🚀 Getting Started

Deployment Prerequisites

Before running Adaptive Graph of Thoughts (either locally or via Docker if not using the provided docker-compose.prod.yml which includes Neo4j), ensure you have:

- A running Neo4j Instance: Adaptive Graph of Thoughts requires a connection to a Neo4j graph database.
- APOC Library: Crucially, the Neo4j instance must have the APOC (Awesome Procedures On Cypher) library installed. Several Cypher queries within the application's reasoning stages utilize APOC procedures (e.g., apoc.create.addLabels, apoc.merge.node). Without APOC, the application will not function correctly. You can find installation instructions on the official APOC website.
- Configuration: Ensure that your config/settings.yaml (or corresponding environment variables) correctly points to your Neo4j instance URI, username, and password.
- Indexing: For optimal performance, ensure appropriate Neo4j indexes are created. You can run python scripts/run_cypher_migrations.py to apply the provided Cypher migrations automatically. See Neo4j Indexing Strategy for details.

Note: The provided docker-compose.yml (for development) and docker-compose.prod.yml (for production) already include a Neo4j service with the APOC library pre-configured, satisfying this requirement when using Docker Compose.

Prerequisites

- Python 3.11+ (as specified in pyproject.toml, e.g., the Docker image uses Python 3.11.x or 3.12.x, 3.13.x)
- Poetry: For dependency management
- Docker and Docker Compose: For containerized deployment

Installation and Setup (Local Development)

1. Clone the repository:

   git clone https://github.com/SaptaDey/Adaptive-Graph-of-Thoughts-MCP-server.git

   cd Adaptive-Graph-of-Thoughts-MCP-server



2. Install dependencies using Poetry:

   poetry install



This creates a virtual environment and installs all necessary packages specified in pyproject.toml.

3. Activate the virtual environment:

   poetry shell



4. Configure the application:

   # Copy example configuration

   cp config/settings.example.yaml config/settings.yaml



   # Edit configuration as needed

   vim config/settings.yaml



5. Set up environment variables (optional):

   # Create .env file for sensitive configuration

   echo "LOG_LEVEL=DEBUG" > .env

   echo "API_HOST=0.0.0.0" >> .env

   echo "API_PORT=8000" >> .env



Secret Management

In production environments, set the SECRETS_PROVIDER environment variable to
aws, gcp, or vault to fetch sensitive values from a supported secrets
manager. Optionally provide <VAR>_SECRET_NAME variables (for example
OPENAI_API_KEY_SECRET_NAME) to control the name of each secret. When a secrets
provider is configured, values for OPENAI_API_KEY, ANTHROPIC_API_KEY, and
NEO4J_PASSWORD are loaded automatically at startup.

6. Run the development server:

   python src/adaptive_graph_of_thoughts/main.py



Alternatively, for more control:

   uvicorn adaptive_graph_of_thoughts.main:app --reload --host 0.0.0.0 --port 8000



The API will be available at http://localhost:8000.

✨ Setup Wizard

An interactive wizard is available to streamline initial configuration.

poetry run python -m agt_setup

Then visit http://localhost:8000/setup to complete the web-based steps.

Setup wizard demo GIF will appear here in the full documentation.

Docker Deployment

graph TB
    subgraph "Development Environment"
        A[👨‍💻 Developer] --> B[🐳 Docker Compose]
    end

    subgraph "Container Orchestration"
        B --> C[📦 Adaptive Graph of Thoughts Container]
        B --> D[📊 Monitoring Container]
        B --> E[🗄️ Database Container]
    end

    subgraph "Adaptive Graph of Thoughts Application"
        C --> F[⚡ FastAPI Server]
        F --> G[🧠 ASR-GoT Engine]
        F --> H[🔌 MCP Protocol]
    end

    subgraph "External Integrations"
        H --> I[🤖 Claude Desktop]
        H --> J[🔗 Other AI Clients]
    end

    style A fill:#e1f5fe
    style B fill:#f3e5f5
    style C fill:#e8f5e8
    style F fill:#fff3e0
    style G fill:#ffebee
    style H fill:#f1f8e9

1. Quick Start with Docker Compose:

   # Build and run all services

   docker-compose up --build



   # For detached mode (background)

   docker-compose up --build -d



   # View logs

   docker-compose logs -f adaptive-graph-of-thoughts



2. Individual Docker Container:

   # Build the image

   docker build -t adaptive-graph-of-thoughts:latest .



   # Run the container

   docker run -p 8000:8000 -v $(pwd)/config:/app/config adaptive-graph-of-thoughts:latest



3. Production Deployment:

   # Use production compose file

   docker-compose -f docker-compose.prod.yml up --build -d



Kubernetes Deployment (Helm)

A minimal Helm chart is provided under helm/agot-server for
running Adaptive Graph of Thoughts on a Kubernetes cluster.

helm install agot helm/agot-server

Customize values in helm/agot-server/values.yaml to set the image repository,
resource limits, and other options.

Notes on Specific Deployment Platforms

- Smithery.ai: Deploy using the included smithery.yaml.
Connect your GitHub repository on Smithery and click Deploy.
The container listens on the PORT environment variable (default 8000).
Health Checks rely on the /health endpoint.
The Dockerfile and docker-compose.prod.yml illustrate the container setup.

4. Access the Services:
- API Documentation: http://localhost:8000/docs
- Health Check: http://localhost:8000/health
- MCP Endpoint: http://localhost:8000/mcp

🔌 MCP Client Integration

Supported MCP Clients

Adaptive Graph of Thoughts supports integration with various MCP clients:

- Claude Desktop - Full STDIO and HTTP support
- VS Code - Via MCP extensions
- Custom MCP Clients - Generic configuration available

Quick Client Setup

Claude Desktop / VS Code settings

{
  "mcpServers": {
    "adaptive-graph-of-thoughts": {
      "command": "python",
      "args": ["-m", "adaptive_graph_of_thoughts.main"],
      "cwd": "/path/to/Adaptive-Graph-of-Thoughts-MCP-server",
      "env": {
        "NEO4J_URI": "bolt://localhost:7687",
        "NEO4J_USER": "neo4j",
        "NEO4J_PASSWORD": "your_password",
        "MCP_TRANSPORT_TYPE": "stdio"
      }
    }
  }
}

Available MCP Tools

| Tool | Description |
|------|-------------|
| scientific_reasoning_query | Advanced scientific reasoning with graph analysis |
| analyze_research_hypothesis | Hypothesis evaluation with confidence scoring |
| explore_scientific_relationships | Concept relationship mapping |
| validate_scientific_claims | Evidence-based claim validation |

🔌 API Endpoints

The primary API endpoints exposed by Adaptive Graph of Thoughts are:

- MCP Protocol Endpoint: POST /mcp
- This endpoint is used for communication with MCP clients like Claude Desktop.
- Example Request for the asr_got.query method:

    {

      "jsonrpc": "2.0",

      "method": "asr_got.query",

      "params": {

        "query": "Analyze the relationship between microbiome diversity and cancer progression.",

        "parameters": {

          "include_reasoning_trace": true,

          "include_graph_state": false

        }

      },

      "id": "123"

    }



- Other supported MCP methods include initialize and shutdown.

- Health Check Endpoint: GET /health
- Provides a simple health status of the application.
- Example Response:

    {

      "status": "healthy",

      "version": "0.1.0"

    }



The advanced API endpoints previously listed (e.g., /api/v1/graph/query) are not implemented in the current version and are reserved for potential future development.

Session Handling (session_id)

Currently, the session_id parameter available in API requests (e.g., for asr_got.query) and present in responses serves primarily to identify and track a single, complete query-response cycle. It is also used for correlating progress notifications (like got/queryProgress) with the originating query.

While the system generates and utilizes session_ids, Adaptive Graph of Thoughts does not currently support true multi-turn conversational continuity where the detailed graph state or reasoning context from a previous query is automatically loaded and reused for a follow-up query using the same session_id. Each query is processed independently at this time.

Future Enhancement: Persistent Sessions

A potential future enhancement for Adaptive Graph of Thoughts is the implementation of persistent sessions. This would enable more interactive and evolving reasoning processes by allowing users to:

1. Persist State: Store the generated graph state and relevant reasoning context from a query, associated with its session_id, likely within the Neo4j database.
2. Reload State: When a new query is submitted with an existing session_id, the system could reload this saved state as the starting point for further processing.
3. Refine and Extend: Allow the new query to interact with the loaded graph—for example, by refining previous hypotheses, adding new evidence to existing structures, or exploring alternative reasoning paths based on the established context.

Implementing persistent sessions would involve developing robust strategies for:
Efficiently storing and retrieving session-specific graph data in Neo4j.
Managing the lifecycle (e.g., creation, update, expiration) of session data.
Designing sophisticated logic for how new queries merge with, modify, or extend pre-existing session contexts and graphs.

This is a significant feature that could greatly enhance the interactive capabilities of Adaptive Graph of Thoughts. Contributions from the community in designing and implementing persistent session functionality are welcome.

Future Enhancement: Asynchronous and Parallel Stage Execution

Currently, the 8 stages of the Adaptive Graph of Thoughts reasoning pipeline are executed sequentially. For complex queries or to further optimize performance, exploring asynchronous or parallel execution for certain parts of the pipeline is a potential future enhancement.

Potential Areas for Parallelism:

Hypothesis Generation: The HypothesisStage generates hypotheses for each dimension identified by the DecompositionStage. The process of generating hypotheses for different, independent dimensions could potentially be parallelized. For instance, if three dimensions are decomposed, three parallel tasks could work on generating hypotheses for each respective dimension.
Evidence Integration (Partial): Within the EvidenceStage, if multiple hypotheses are selected for evaluation, the "plan execution" phase (simulated evidence gathering) for these different hypotheses might be performed concurrently.

Challenges and Considerations:

Implementing parallel stage execution would introduce complexities that need careful management:

Data Consistency: Concurrent operations, especially writes to the Neo4j database (e.g., creating multiple hypothesis nodes or evidence nodes simultaneously), must be handled carefully to ensure data integrity and avoid race conditions. Unique ID generation schemes would need to be robust for parallel execution.
Transaction Management: Neo4j transactions for concurrent writes would need to be managed appropriately.
Dependency Management: Ensuring that stages (or parts of stages) that truly depend on the output of others are correctly sequenced would be critical.
Resource Utilization: Parallel execution could increase resource demands (CPU, memory, database connections).
Complexity: The overall control flow of the GoTProcessor would become more complex.

While the current sequential execution ensures a clear and manageable data flow, targeted parallelism in areas like hypothesis generation for independent dimensions could offer performance benefits for future versions of Adaptive Graph of Thoughts. This remains an open area for research and development.

🧪 Testing & Quality Assurance

<div align="center">
<table>
<tr>
<td align="center">🧪<br><b>Testing</b></td>
<td align="center">🔍<br><b>Type Checking</b></td>
<td align="center">✨<br><b>Linting</b></td>
<td align="center">📊<br><b>Coverage</b></td>
</tr>
<tr>
<td align="center">
<pre>poetry run pytest</pre>
<pre>make test</pre>
</td>
<td align="center">
<pre>poetry run mypy src/</pre>
<pre>pyright src/</pre>
</td>
<td align="center">
<pre>poetry run ruff check .</pre>
<pre>poetry run ruff format .</pre>
</td>
<td align="center">
<pre>poetry run pytest --cov=src</pre>
<pre>coverage html</pre>
</td>
</tr>
</table>
</div>

Development Commands

Continuous integration pipelines on GitHub Actions run tests, CodeQL analysis, and Microsoft Defender for DevOps security scans.

```bash
